CJ40 series AC contactors are mainly used to connect and break circuits in power systems with AC 50Hz or 60Hz, voltage up to 660V or 1140V, and current up to 1000A; and can be combined with appropriate thermal relays or electronic protection devices Combined into motor starters to protect circuits where overloading may occur. This product complies with IEC60947-4-1, GB14048.4 and JB/T8591.1 standards.

Main parameters and technical performance indicators:

Contactor model: CJ40-800

Rated insulation voltage Ui V: 1140

Conventional heating current A:630

Number of operating cycles per hour/h (AC-3): 300

AC-3 electric life ten thousand times: 30

Coil power:

Starting VA: 456

Maintain VA: 11.5

Recommended fuse (SCPD) model: RT17-4/800
