The PC817X family contains an IRED optically coupled to a phototransistor. It is available in a 4-pin DIP package with comprehensive lead spacing options and SMT gull-wing lead style options. The input and output isolation voltage (RMS) is 5.0kV. The collector-emitter voltage is 80V(*), and the CTR is 50% to 600% at an input current of 5mA.

Features:

1. 4pin DIP package

2. Double transfer mold package (ideal for flow soldering)

3. High collector-emitter voltage (VCEO:80V(*))

4. Current transfer ratio (CTR: MIN. 50% at IF=5 mA, VCE=5V)

5. High isolation voltage between input and output (Viso(RMS): 5.0 kV)
